Features
- High-performance brushless speed controller with 32-bit technology
- Latest generation of MosFets for reduced power loss and maximum
possible reliability
- Telemetry for PowerBox, Jeti and Futaba radio control systems
- Fixed-wing and Helicopter modes
- Adjustable direction of rotation, timing, battery type, freewheel, start-up
current and other parameters
- Adjustable regulatory parameters in helicopter mode
- Parameters directly adjustable from PowerBox and Jeti transmitters
- Parameters adjustable using LCD programming device for all systems
- 8A BEC
- Power-on self-test checks motor, throttle position and voltage
- Ingenious case design ensures optimum cooling
|
|
Technical Data
| Operating voltage |
3s - 6s |
| Maximum load current |
65A/75A Continous/Peak |
| Output voltage |
6.0V/7.4V/8.4V BEC |
| Signal input |
PWM |
| Supported RC systems |
PowerBox, Jeti, Futaba, others without telemetry |
| Supported telemetry systems |
P²-BUS, EX-BUS, S.BUS2 |
| Dimensions |
60 x 36 x 20 mm |
| Weight |
72g |
|
